[2B529482 & Up] - USA - Cat.# 90-8M0145604

PartsDiagramEngine

Top Cowl

22 parts

−100%+1:1

Pinch with two fingers or use the wheel/double-tap to zoom, drag to pan.

Search this catalog

Groups (34)−

• 01Top Cowl22
• 02Tools39
• 03Service/Support Material7
• 04Oil System45
• 05Maintenance Kits19
• 06Intake System Design II34
• 07Intake System Design I36
• 08Ignition7
• 09Gear Housing, Prop Shaft - Standard Rotation, 5.44 Torpedo (1.75 Gear Ratio)36
• 10Gear Housing, Prop Shaft - Standard Rotation, 4.80 Torpedo (1.85 Gear Ratio)34
• 11Gear Housing, Prop Shaft - Counter Rotation, 5.44 Torpedo37
• 12Gear Housing, Driveshaft, Torque Master 1.7541
• 13Gear Housing, Driveshaft - 5.44 Torpedo (1.75 Gear Ratio)53
• 14Gear Housing, Driveshaft - 4.80 Torpedo (1.85 Gear Ratio)47
• 15Gear Housing Prop Shaft-Standard Rotation,Torque Master33
• 16Fuel System33
• 17Flywheel 3B056353 and Up4
• 18Flywheel 3B056352 and Below3
• 19Exhaust 3B050618 and Up42
• 20Exhaust 3B050617 and Below39
• 21Electrical69
• 22Driveshaft Housing20
• 23Driveshaft Extension Kits26
• 24Decals31
• 25Cylinder Head and Camshaft83
• 26Cylinder Block42
• 27Crankshaft, Pistons and Connecting Rods22
• 28Cooling System54
• 29Camshaft Cover12
• 30Alternator Mounting/Belt 3B056353 and Up18
• 31Alternator Mounting/Belt 3B056352 and Below11
• 32Adapter Plate31
• 33Accessories58
• 34Accent Panel8

• 1
  8M0142173TOP COWL ASSEMBLY Decaled without HorsepowerSuperseded by: 8M0182329
  ask for price+ Add to Cart
• 2
  8M0142904ALIGNMENT LEG KIT · qty 4
  ask for price+ Add to Cart
• 3
  8M0178589SCREW M6 x 12 · qty 8
  ask for price+ Add to Cart
• 4
  8M0142916BUMPER Port
  ask for price+ Add to Cart
• 5
  8M0142915BUMPER Starboard
  ask for price+ Add to Cart
• 6
  8M0142906SEAL Top CowlSuperseded by: 8M0182085
  ask for price+ Add to Cart
• 7
  8M0142242COWL LATCH ASSEMBLYSuperseded by: 8M0183790
  ask for price+ Add to Cart
• 8
  8M0103806SCREW (M6 x 20 mm) Stainless Steel · qty 10Out of stock
  133.36 ₺+ Add to Cart
• 9
  8M0142903CLIP · qty 7
  ask for price+ Add to Cart
• 10
  8M0142955SCREW (M5 x 0.8) · qty 2
  ask for price+ Add to Cart
• 11
  8M0142954CLIP · qty 2
  ask for price+ Add to Cart
• 12
  88552514SCREW (M6 x 14 mm) Stainless Steel · qty 8
  ask for price+ Add to Cart
• 13
  8M0219155BEZEL ASSEBMBLY Port/StarboardIn stock
  4,627.08 ₺+ Add to Cart
• 14
  8M0142238DOOR ASSEMBLY BlackSuperseded by: 8M0157771
  ask for price+ Add to Cart
• 15
  8M0142913KEEPER ASSEMBLYOut of stock
  816.60 ₺+ Add to Cart
• 16
  8M0204400SCREW Thread Forming · qty 2
  ask for price+ Add to Cart
• 17
  8M0142908SEAL Door
  ask for price+ Add to Cart
• 18
  8M0148533DECAL Latch Position
  ask for price+ Add to Cart
• 19
  8M0142907LOCK PUSHOut of stock
  6,137.54 ₺+ Add to Cart
• 20
  8M0142914SHIM SET LatchOut of stock
  2,278.75 ₺+ Add to Cart
• 21
  401386NUT (M6) Stainless SteelOut of stock
  171.53 ₺+ Add to Cart
• 22
  8M0187755WATER DIVERTEROut of stock
  1,279.02 ₺+ Add to Cart

Drawings are Mercury technical assembly diagrams; the callout number matches the part in the list. Serial number, revision and part number are confirmed before ordering.
