[2B529482 & Up] - USA - Cat.# 90-8M0142638

PartsDiagramEngine

Top Cowl

20 parts

−100%+1:1

Pinch with two fingers or use the wheel/double-tap to zoom, drag to pan.

Search this catalog

Groups (17)−

• 01Top Cowl20
• 02Swivel Bracket and Steering Arm31
• 03Service/Support Material7
• 04Power Trim/Transom Assembly41
• 05Lower Cowl49
• 06Intake System28
• 07Gear Housing Prop Shaft - Standard Rotation, 4.80 Torpedo50
• 08Gear Housing Driveshaft, 4.80 Torpedo53
• 09Exhaust 3B050618 and Up43
• 10Exhaust 3B050617 and Below40
• 11Electrical64
• 12Driveshaft Housing23
• 13Driveshaft Extension Kits18
• 14Decals23
• 15Cooling System53
• 16Accessories54
• 17Accent Panel12

• 1
  8M0142179TOP COWL ASSEMBLY Pro XS, Decaled without HorsepowerSuperseded by: 8M0182322
  ask for price+ Add to Cart
• 2
  8M0142904ALIGNMENT LEG KIT · qty 4
  ask for price+ Add to Cart
• 3
  8M0178589SCREW M6 x 12 · qty 8
  ask for price+ Add to Cart
• 4
  8M0142916BUMPER Port
  ask for price+ Add to Cart
• 5
  8M0142915BUMPER Starboard
  ask for price+ Add to Cart
• 6
  8M0173441SEAL Top CowlSuperseded by: 8M0182085
  ask for price+ Add to Cart
• 7
  8M0142243COWL LATCH ASSEMBLYSuperseded by: 8M0183791
  ask for price+ Add to Cart
• 8
  8M0103806SCREW (M6 x 20 mm) Stainless Steel · qty 10Out of stock
  135.74 ₺+ Add to Cart
• 9
  8M0142903CLIP · qty 7
  ask for price+ Add to Cart
• 10
  88552514SCREW (M6 x 14 mm) Stainless Steel · qty 8
  ask for price+ Add to Cart
• 11
  8M0219156BEZEL ASSEMBLY Port/StarboardIn stock
  6,713.10 ₺+ Add to Cart
• 12
  8M0142233DOOR ASSEMBLY BlackSuperseded by: 8M0155319
  ask for price+ Add to Cart
• 13
  8M0142913KEEPER ASSEMBLYOut of stock
  831.15 ₺+ Add to Cart
• 14
  8M0204400SCREW Thread Forming · qty 2
  ask for price+ Add to Cart
• 15
  8M0142908SEAL Door
  ask for price+ Add to Cart
• 16
  8M0148533DECAL Latch Position
  ask for price+ Add to Cart
• 17
  8M0142907LOCK PUSHOut of stock
  6,246.87 ₺+ Add to Cart
• 18
  8M0142914SHIM SET LatchOut of stock
  2,319.34 ₺+ Add to Cart
• 19
  401386NUT (M6) Stainless SteelOut of stock
  174.59 ₺+ Add to Cart
• 20
  8M0187754WATER DIVERTERIn stock
  1,291.47 ₺+ Add to Cart

Drawings are Mercury technical assembly diagrams; the callout number matches the part in the list. Serial number, revision and part number are confirmed before ordering.
